1064001257
HongPro
1064001257
This premium Front Right Shock Absorber is engineered to restore your vehicle's original driving comfort and safety. It effectively controls spring oscillation, ensuring optimal tire contact with the road for superior handling and stability, especially on bumpy surfaces or during cornering.
Manufactured to meet or exceed OE specifications, each unit undergoes rigorous testing, including a minimum of 1.5 million cycles of endurance testing, to guarantee long-term reliability. Key features include:
Precise Damping: Computer-tuned valving for consistent response.
Robust Construction: A hardened piston rod with multi-layer sealing for superior corrosion resistance and leak-proof performance.
Durability: High-quality fluid minimizes performance degradation under extreme temperatures.
This direct-fit replacement is the trusted choice for professional mechanics and DIY enthusiasts seeking uncompromised quality and a smooth, controlled ride.
Our front right shock absorber is subjected to extreme endurance testing to ensure a service life that far exceeds industry standards. Each unit is simulated to withstand over 1.5 million cycles of piston travel testing before leaving the factory, equivalent to driving more than 80,000 kilometers on harsh roads. This guarantees long-term performance stability and reliability, effectively reducing the risk of failure and repeat purchase costs for your customers.
We utilize Computer-Aided Engineering (CAE) to precisely calibrate the internal damping valve system. This ensures the shock absorber generates the optimal damping force across all piston velocities. This technology efficiently and rapidly absorbs road impacts, eliminating excessive bounce and providing excellent body control and superior tire grip during braking, acceleration, and cornering, directly enhancing driving safety and comfort.
Built to withstand diverse climatic conditions, our shock absorbers feature a high-strength, zinc-plated piston rod combined with a triple-seal system. The zinc plating thickness reaches 15-20μm, offering significantly superior rust protection compared to standard coatings. The internal high-precision seals effectively prevent oil leakage and contaminant ingress, ensuring consistent, like-new performance even in humid, saline, or dusty environments, thereby extending the product's lifecycle.
Every front right shock absorber undergoes 100% performance testing before shipment, guaranteeing its damping curve closely matches Original Equipment (OE) specifications. Our production line is certified under the IATF 16949:2016 international automotive quality management system, with strict quality control from raw materials to finished product. This ensures every unit you receive is a high-quality, ready-to-install replacement part with consistent performance.
| Parameter Category | Specification Details |
| Product Identification | Type: Twin-Tube, Gas-Charged |
| Physical Dimensions | Extended Length: 495 ± 3 mm Compressed Length: 310 ± 3 mm Stroke: 185 mm Mounting Eye Inner Diameter: 12.7 mm (Top), 22.2 mm (Bottom) |
| Performance Parameters | Damping Force (Rebound): 1150 N ± 50 N @ 0.52 m/s Damping Force (Compression): 380 N ± 40 N @ 0.52 m/s Operating Temperature Range: -40°C to +120°C |
| Material & Construction | Piston Rod: High-Strength Steel, Chrome-Plated (Thickness: 25-30 µm) Cylinder Tube: Precision Seamless Steel Tube Fluid Type: High-Viscosity Index, Silicon-based Hydraulic Oil |
| Quality & Testing | Endurance Cycle Test: > 2.0 Million Cycles (Simulating 100,000 km) Leakage Test: Zero Leakage under maximum pressure Quality Management System: IATF 16949:2016 Certified |
Here are specific application scenarios of Shock Absorber:
This shock absorber is engineered for the constant demands of city driving, including frequent stops, speed bumps, and uneven road surfaces. It effectively dampens minor vibrations, ensuring a smooth and comfortable ride while protecting other suspension components from excessive impact. Its exceptional durability, proven through testing of over 1.5 million cycles, ensures long-lasting performance against daily wear, reducing maintenance frequency and costs for vehicle owners.
During long-distance highway travel, vehicle stability and handling are paramount. With its precise damping calibration, this shock absorber provides strong support during high-speed lane changes or when encountering road undulations, effectively minimizing body roll and ensuring superior tire grip. This significantly boosts driver confidence and control at high speeds, making it a critical component for journey safety.
When original shock absorbers show signs of wear like fluid leakage, noise, or reduced handling, our product is the perfect direct replacement. Its OE-standard mounting points guarantee a perfect fit without any modification. For repair shops and professional technicians, offering this high-quality part enhances customer satisfaction, reduces comebacks, and builds a reputation as a reliable supplier.
For optimal performance and safety, we strongly recommend professional installation by a certified mechanic. Prior to installation, always conduct a visual inspection of the new shock absorber to ensure no transit damage has occurred. It is critical to replace shock absorbers in pairs (both front left and right) to maintain balanced handling and stability. After installation, a wheel alignment is essential to ensure proper vehicle geometry. Avoid impacting the piston rod during handling to prevent damage to the chrome surface and seals.
