Product Introduction
1119100XP6PXA radiator for Great Wall Motor
Designed exclusively for Great Wall Motor, this aluminum-core radiator is a critical cooling system component. It features a dense fin structure that boosts heat exchange area, enabling efficient heat dissipation to prevent engine overheating. Built to withstand high temperatures and pressure, it undergoes strict 100% QC and pressure tests to meet or exceed industry standards. With OEM-compatible design for easy installation, it enhances engine stability and reduces thermal decay even under intense use. Backed by professional manufacturing experience, it delivers long-lasting reliability.
Product Advantage
1.Premium Aluminum Core Construction
Crafted with aviation-grade aluminum alloy, the radiator core boasts a 35% higher heat conductivity than standard materials. Its 0.8mm-thick core structure and 120pcs/inch dense fin design expand heat exchange area by 40%, ensuring rapid heat dissipation. This material also reduces overall weight by 25% while enhancing corrosion resistance, proven by 500-hour salt spray tests to meet Great Wall Motor’s strict standards.2. High-Pressure Resistant Design
Engineered to withstand up to 1.8 bar working pressure, this Great Wall Motor radiator passes 100% air-tightness detection (leakage rate ≤ 0.01MPa/min). The reinforced tank-to-core connection and anti-burst sealing ring prevent coolant leakage even under extreme temperature fluctuations (-40℃ to 120℃), reducing maintenance risks by 60%.
3.OEM-Level Compatibility & Easy Installation
Precision-machined according to original Great Wall Motor specifications (tolerance ±0.02mm), the radiator fits seamlessly with existing cooling systems. It comes with pre-drilled mounting holes and matching hardware, cutting installation time to 30 minutes on average—no need for modified parts. 98% of mechanics confirm its hassle-free replacement experience.
4. Enhanced Cooling Efficiency for Intense Use
Equipped with a turbulence-enhanced internal channel design, the radiator improves coolant circulation speed by 28%. It effectively lowers engine operating temperature by 15-20℃ during heavy loads (e.g., towing, off-roading). Test data shows it maintains stable cooling performance for 80,000+ miles, outperforming generic radiators by 35%.
5. Strict Quality Control & Reliable Warranty
Each radiator undergoes 7-step quality checks, including material composition analysis, pressure testing, and thermal performance evaluation. With a 5-year/100,000-mile warranty, it’s backed by a factory with 15+ years of auto cooling system manufacturing experience. Our defect rate remains below 0.3%, ensuring long-term reliability.
Technical Parameters
Parameter Category
| Details
|
| Core Construction | Material: Aviation-grade 3003 aluminum alloyCore Thickness: 38mmFin Density: 120 fins per inchTube Diameter: 8mmHeat Exchange Area: 1.8 m² |
| Overall Dimensions | Length: 650mm ± 2mmWidth: 420mm ± 2mmHeight: 75mm ± 1mmNet Weight: 4.2kg ± 0.1kg |
| Cooling Performance | Heat Dissipation Capacity: 5500 WCoolant Flow Rate: 8 L/minOperating Temperature Range: -40℃ to 120℃Pressure Drop: ≤ 0.2 bar |
| Pressure Resistance | Maximum Working Pressure: 1.8 barPressure Test Standard: 2.5 bar (30 minutes, no leakage)Leakage Rate: ≤ 0.01 MPa/min |
| Material & Durability | Tank Material: Reinforced PA66+GF30 plasticSealing Ring: EPDM rubber (oil/fuel resistant)Salt Spray Test: 500 hours (no corrosion)Service Life: ≥ 80,000 miles |
| Compatibility & Installation | Mounting Type: Direct OEM fitTolerance: ±0.02mmConnection Inlet/Outlet Diameter: 28mm / 25mmInstallation Time: ~30 minutes (average) |
| Quality & Certification | Quality Control: 7-step inspection processDefect Rate: < 0.3%Certifications: ISO 9001, IATF 16949 |
| Environmental Compliance | Recyclability: ≥ 95% (aluminum components)Heavy Metal Content: Complies with EU REACH regulationsCoolant Compatibility: Ethylene glycol / propylene glycol-based |
Product Uses
Here are specific application scenarios of radiator:
1.Heavy-Duty Commercial Use
Ideal for Great Wall Motor vehicles used in logistics or delivery, where continuous 8-12 hour operation is common. Its 5500W heat dissipation capacity keeps engines cool, reducing overheating risks by 60% during long-haul trips, as verified by 100+ fleet tests.
2.Off-Road & Extreme Terrain Driving
Performs reliably in deserts, mountains, or muddy areas. Withstands -40℃ to 120℃ temperature swings and 1.8 bar pressure, maintaining stable cooling even when climbing steep slopes. Tested to keep engines 15-20℃ cooler under extreme loads.
3. Daily Urban Commuting
Perfect for stop-and-go city traffic, where frequent engine idling causes heat buildup. The 120 fins/inch dense core accelerates heat exchange, lowering operating temperature quickly. Reduces fuel consumption by 3-5% for daily 50-mile commutes.
4. Towing & Load-Carrying Scenarios
Essential when hauling trailers or heavy cargo. The turbulence-enhanced channels boost coolant circulation by 28%, preventing thermal decay. Ensures engine stability for 80,000+ miles of towing use, per factory durability tests.
Excels in regions with year-round high temperatures (35℃+). Its large 1.8 m² heat exchange area dissipates heat efficiently, avoiding engine overheating. Proven effective in Southeast Asian and Middle Eastern markets via local user feedback.
Product Operate Guide
Perfect for Great Wall Motor vehicles in 8-12h commercial logistics (cuts overheating risks by 60% via 5500W dissipation), off-road terrain (-40℃ to 120℃ tolerance, 1.8 bar pressure resistance), and urban commutes (120 fins/inch core saves 3-5% fuel). Ideal for towing (28% faster coolant flow, 80k+ mile stability) and 35℃+ hot climates (1.8 m² exchange area).
