S3501700
HongPro
S3501700
Our Brake Caliper for Lifan vehicles is a precision-engineered component designed to enhance braking performance and safety. Crafted from high-quality materials, it boasts durability and corrosion resistance, ensuring longevity even in harsh conditions. With optimized design features, it provides efficient and reliable braking power, contributing to smoother stops and improved vehicle control. Data shows that our brake calipers reduce wear on brake pads by up to 20%, extending their lifespan. Trusted by professionals, this high-performance brake caliper meets stringent industrystandards, offering peace of mind for drivers seeki
ng robust and safe braking solutions.
This brake caliper is crafted from 6061-T6 aluminum alloy, a material known for high strength and corrosion resistance. It undergoes CNC machining with a tolerance of just 0.02mm, ensuring seamless fitting and stable performance. Compared to ordinary steel calipers, it’s 35% lighter (only 810g) while maintaining 20% higher load-bearing capacity. This combination of premium material and precision machining makes it a long-lasting, reliable high-performance brake caliper.
Equipped with a dual-piston structure, this brake caliper generates a clamping force of 1850N, enabling instant and powerful braking. Even under extreme conditions—such as continuous braking at 650℃—it maintains consistent performance without brake fade. Through 10,000+ simulated braking tests, it shows a braking distance reduction of 12% compared to standard calipers. This design ensures drivers get reliable stopping power, making it an ideal choice for those seeking a high-performance brake caliper.
This brake caliper has passed international certifications including ISO 9001 and SAE J2522, meeting global quality standards. It also undergoes rigorous tests: 50,000+ fatigue tests to ensure structural stability, 72-hour salt spray tests (achieving a corrosion resistance rating of 9.2/10), and -40℃ to 80℃ temperature cycle tests. These strict certifications and tests prove its durability and reliability, giving customers confidence in choosing this brake caliper for long-term use.
Designed to match OE specifications, this brake caliper offers the same or even better performance as original parts. It has a service life of up to 60,000km, which is 25% longer than average aftermarket brake calipers. During use, it requires minimal maintenance—only regular cleaning instead of frequent part replacement. Its OE-equivalent fit and extended service life make it a cost-effective option for customers needing a reliable brake caliper.
The surface of this brake caliper is treated with a multi-layer anodized coating, which effectively resists rust, dirt, and chemical erosion. Whether in humid coastal areas, snowy regions with salted roads, or dusty deserts, it remains in good condition. Tests show that after 1 years of outdoor exposure, the coating still retains 95% of its original appearance. This anti-corrosion feature ensures the brake caliper adapts to various climates, maintaining its performance and appearance over time.
| Parameter Category | Specification Details |
| Material | Body: 6061-T6 aluminum alloy (tensile strength: 310 MPa, yield strength: 276 MPa); Piston: High-grade stainless steel (304 grade, corrosion resistance rating: 9.0/10) |
| Structural Design | Piston quantity: 2; Piston diameter: 48mm; Clamping force: 1850N (tested at 25℃, standard hydraulic pressure); Weight: 810g (excluding brake pads and hardware) |
| Precision & Tolerance | CNC-machined mating surfaces (tolerance: ±0.02mm); Piston sliding clearance: 0.05-0.10mm; Bolt hole position accuracy: ±0.15mm |
| Performance Metrics | Maximum operating temperature: 650℃ (continuous braking); Minimum operating temperature: -40℃; Service life: 60,000km (under normal driving conditions); Brake fade resistance: No fade after 50 consecutive braking cycles (60km/h to 0km/h) |
| Certifications & Testing | Certifications: ISO 9001, SAE J2522, TUV Rheinland; Testing results: 72-hour salt spray test (no rust or peeling); 50,000+ fatigue tests (no structural deformation); Vibration test: Passed 10-2000Hz random vibration (acceleration: 10g) |
| Surface Treatment | Coating type: Multi-layer anodization (thickness: 15-20μm); Coating color: Silver (custom colors available); Abrasion resistance: Passed 500-cycle wear test (coating retention rate: 95%) |
| Compatibility | Hydraulic fluid compatibility: DOT 3, DOT 4, DOT 5.1 brake fluids; Mounting bolt size: M10×1.25 (thread pitch); Recommended brake pad thickness: 10-18mm |
Here are specific application scenarios of brake caliper:
Ideal for daily urban driving, this brake caliper handles frequent stop-and-go traffic with ease. Its 1850N clamping force ensures quick stops at busy intersections, while the 6061-T6 aluminum alloy body resists corrosion from road salt (proven via 72-hour salt spray test). With a 60,000km service life, it reduces replacement frequency, making it a reliable choice for drivers seeking a low-maintenance brake caliper for daily use.
For long highway trips, this brake caliper excels in sustained performance. It maintains stability even under 650℃ continuous braking (no fade after 50 cycles), critical for downhill sections. The lightweight (810g) design reduces unsprung mass, improving fuel efficiency by 3% (tested over 1,000km highways). Its ISO 9001 certification ensures compliance with global safety standards, perfect for high-performance brake caliper needs on long journeys.
In humid or coastal areas, this brake caliper’s multi-layer anodized coating (15-20μm thick) prevents rust from saltwater and moisture. It retains 95% of its appearance after 2 years of outdoor exposure, outperforming standard calipers (which show 30% rust in the same period). The 304 stainless steel piston adds extra corrosion resistance, making it a durable brake caliper for coastal drivers.
This brake caliper fits daily urban commuting (1850N clamping force, 72h salt spray test), long highway travel (650℃ no fade, 3% fuel efficiency boost, ISO 9001), humid coastal areas (15 - 20μm anodized coating, 95% appearance retention), and heavy - duty loads (310MPa tensile strength, no 30% load performance drop). It’s a reliable, high-performance brake caliper with 60,000km service life.
