Product Introduction
SS35001 Premium Long-Lasting Low-Noise Brake Pad for Lifan
With over 10 years of R&D and manufacturing experience in automotive braking systems, we present the SS35001 brake pad—a reliable choice for optimal stopping performance.
It features a premium friction material with a stable coefficient of 0.38-0.42, ensuring consistent braking force in diverse road conditions. The pad delivers a service life of over 50,000 kilometers, reducing replacement frequency.
Compliant with ECE R90 and FMVSS 135 global safety standards, and certified by ISO 9001, it minimizes noise (≤65dB) and brake dust, while protecting brake discs from excessive wear
Product Advantage
1. Premium Friction Material for Stable Braking Performance
The SS35001 brake pad adopts a high-grade ceramic-enhanced friction compound, developed through 10+ years of R&D. It maintains a stable friction coefficient of 0.38-0.42 across a wide temperature range (-30℃ to 600℃), avoiding brake fade during high-speed or frequent braking. This material also reduces abrasion on brake discs, extending the overall service life of the braking system.
2. Long-Lasting Durability with 50,000+ km Service Life
Tested under simulated urban and highway driving conditions, the SS35001 brake pad delivers a service life of over 50,000 kilometers—20% longer than the industry average for standard brake pads. Its advanced heat-dissipating structure prevents material degradation from high temperatures, ensuring consistent performance even after prolonged use. This durability minimizes replacement frequency for end-users, cutting long-term maintenance costs.
3. Global Safety Certifications for Reliable Compliance
The SS35001 brake pad is fully compliant with strict international standards, including ECE R90 (European safety regulation for braking systems) and FMVSS 135 (U.S. Federal Motor Vehicle Safety Standard). It also holds ISO 9001 quality management certification, guaranteeing each unit meets uniform quality benchmarks. In third-party tests, it achieved a 15% shorter braking distance compared to uncertified alternatives, enhancing driving safety.
4. Low-Noise & Low-Dust Design for Enhanced User Experience
Equipped with a noise-dampening steel backing plate and a dust-reducing friction formula, the SS35001 brake pad operates at ≤65 decibels—quieter than the 75dB average of conventional brake pads. It also reduces brake dust by 30%, keeping wheels cleaner and reducing the need for frequent cleaning. This design addresses two common pain points for users, improving overall satisfaction with the braking system.
5. 100% Pre-Delivery Testing for Consistent Quality
Every SS35001 brake pad undergoes rigorous pre-delivery testing, including friction coefficient verification, heat resistance checks, and dimensional accuracy inspections. Our factory’s 10+ years of manufacturing experience ensure a 99.8% pass rate for outgoing products. This strict quality control process eliminates defective units, giving customers confidence that each brake pad will perform as expected from the first use.
Technical Parameters
| Parameter Category | Specific Parameter | Specification / Data | Remarks & Compliance Standards |
| Basic Information | Product Model | SS35001 | Customizable part number for bulk orders |
| Product Type | Disc Brake Pad | For passenger cars & light commercial vehicles |
| Application Scope | Hydraulic braking systems | Compatible with most standard hydraulic setups |
| Material Composition | Friction Material Type | Ceramic-enhanced composite | Blend of ceramic particles, glass fiber, and aramid fiber |
| Backing Plate Material | Cold-rolled steel (CR4) | Thickness: 3.0mm, high torsional strength |
| Surface Coating | Electrophoretic anti-rust coating | Salt spray test resistance ≥ 48 hours |
| Performance Metrics | Friction Coefficient (μ) | 0.38 - 0.42 | Tested at 100-300℃, compliant with ECE R90 |
| High-Temperature Stability | -30℃ to 600℃ | No brake fade within operating temperature range |
| Wear Rate | ≤ 0.3 cm³/(MJ) | Extends service life to ≥ 50,000 km |
| Noise Level | ≤ 65 dB | Measured at 40-80 km/h, lower than industry average (75 dB) |
| Safety Certifications | International Standards | ECE R90, FMVSS 135, ISO 9001 | Passed impact, fatigue, and braking efficiency tests |
| Physical Dimensions | Length | 140 - 160 mm (adjustable for specific fits) | Tolerance: ±0.5mm |
| Width | 55 - 65 mm | Tolerance: ±0.3mm |
| Thickness (Friction Material) | 12 - 14 mm | Initial thickness, no break-in required |
| Total Weight (Per Pad) | 350 - 400 g | Includes backing plate and friction material |
| Test Standards | Bench Test | Simulated 50,000 km driving cycles | 99.8% pass rate in factory pre-delivery tests |
| Environmental Adaptability | -40℃ (low-temp storage) to 70℃ (high-temp storage) | No material degradation after 12-month storage |
Product Uses
Here are specific application scenarios of brake pad:
1. Urban Daily Commuting
Ideal for frequent start-stop cycles in cities. Its stable friction coefficient (0.38-0.42) ensures smooth braking during rush-hour traffic, while the ≤65dB noise level avoids disturbing urban environments. The ceramic-enhanced material also resists wear from short-distance trips, maintaining 50,000+ km service life even in dense traffic.
2. Highway Long-Distance Driving
Excels in high-speed braking scenarios. It withstands temperatures from -30℃ to 600℃, preventing brake fade during prolonged highway runs. Third-party tests show it shortens braking distance by 15% compared to uncertified pads, meeting FMVSS 135 standards to keep drivers safe at high speeds.
3. Mountainous & Hilly Road Conditions
Perfect for continuous downhill braking. Its low wear rate (≤0.3 cm³/(MJ)) reduces material loss from repeated braking, avoiding overheating risks. The heat-dissipating structure ensures consistent performance on steep slopes, and the 50,000+ km service life minimizes replacement stops for long mountain trips.
4. Extreme Climate Environments
Adapts to harsh weather—from cold winters (-40℃ storage stability) to hot summers (70℃ high-temp resistance). The anti-rust coating prevents corrosion in rainy or coastal areas, while the friction material’s stability ensures no performance drop in humidity or dry heat, complying with global climate adaptability standards.
Product Operate Guide
For optimal performance (per our 10+ years of braking industry experience), have the pad installed by a certified technician—this ensures compliance with ECE R90 safety standards.
Before installation, clean the brake caliper and rotor to remove debris; this preserves the 0.38-0.42 friction coefficient. Check the pad monthly: replace when friction material thickness drops below 3mm. Avoid sudden, excessive braking to maintain its 50,000+ km service life.
