1014013212
HongPro
1014013212
Our Right Front Shock Absorber, crafted with OE-certified quality and IATF 16949/ISO 9001 authentication, fits mainstream European and American models. It absorbs road impacts, reducing body roll by 12% and braking pitch by 18% for enhanced stability . With a 50,000-100,000-mile service life under normal conditions, it protects suspension systems . Rigorously tested, it ensures Original factory level performance, balancing comfort and safety for reliable driving
As a team with 15 years of experience in automotive parts research and development, our Right Front Shock Absorber has passed the IATF 16949 automotive industry quality certification and ISO 9001 standard certification. Each product is produced according to the original OE specifications and accurately adapts to mainstream models, with an installation matching degree of 99.2%, avoiding suspension failures caused by dimensional deviations.
The product adopts a dual tube hydraulic damping structure with a built-in high-pressure nitrogen tank. Through third-party laboratory testing, it can reduce body roll by 18% and brake nod by 12%. When driving on bumpy roads (such as gravel roads), the vibration transmission rate is reduced by 25%, effectively protecting the tires and suspension system, making driving smoother - this is also our high stability Right Front Shock Absorber core competitiveness.
the piston rod is made of 45 # chrome plated alloy steel, with a surface hardness of HRC 58-62 and a 30% increase in corrosion resistance; The seal is made of imported nitrile rubber, which can withstand high and low temperatures ranging from -40 ℃ to 120 ℃. Under normal use, the service life of the long life Right Front Shock Absorber can reach 50000-100000 miles, which is 20% higher than the industry average.
Each Right Front Shock Absorber must undergo three core tests before leaving the factory: 100000 reciprocating damping tests (to ensure stable damping force), salt spray tests (to simulate a 3-year outdoor corrosive environment), and high and low temperature cycling tests (to verify extreme environmental adaptability). The pass rate of the tests is 100%, eliminating driving safety hazards caused by unstable performance.
The product comes with an original factory specification installation manual, which does not require additional modifications to the suspension structure. Ordinary maintenance technicians can complete the installation within 30 minutes, saving 30% of installation time compared to similar products; We also provide a 2-year/30000 mile warranty service, with an after-sales response time of ≤ 24 hours and a customer satisfaction rate of 96.5%, solving your worries.
| Parameter Category | Parameter Name | Specific specifications/data | Test standards/notes |
| Basic Information | OE code | 1014013212 | Match 1:1 with the original OE code to ensure compatibility |
| Structure and properties | Structural type | Double tube hydraulic type (with high-pressure nitrogen tank) | Industry mainstream stable structure, reducing damping attenuation |
| Damping force range | Compression stroke: 1200-1400N; rebound stroke: 1500-1800N | Tested according to ISO 18830 standard, the damping force deviation is ≤± 5% | |
| Maximum stroke | Compression stroke: 65mm; rebound stroke: 80mm | Adapt to the original suspension travel to avoid excessive compression damage | |
| Working pressure | 2.5-3.0MPa | No leakage under high pressure, ensuring stability during high-speed driving | |
| Material Specifications | Material of piston rod | 45 # chrome plated alloy steel | Surface hardness HRC 58-62, surface roughness Ra ≤ 0.2 μ m |
| Cylinder material | ST52-3 seamless steel pipe | Wall thickness 3.5mm, tensile strength ≥ 510MPa | |
| Seal material | Imported nitrile rubber (NBR)+polytetrafluoroethylene (PTFE) | Temperature resistance range -40 ℃~120 ℃, oil resistance grade ISO 6072 | |
| Material of connecting components | 40Cr alloy cast iron | Impact resistance strength ≥ 80J/cm ² to avoid installation fracture | |
| Environmental adaptability | Salt spray test tolerance time | ≥ 480 hours | Compliant with ASTM B117 standard, with no rust spots on the surface |
| High and low temperature cycling test | -40 ℃~120 ℃, 200 cycles | The damping force change rate after cycling is ≤ 5%, and the sealing performance is normal | |
| Vibration fatigue test | 100000 reciprocating vibrations (10Hz frequency) | After testing, there is no oil leakage or structural deformation, and the damping force meets the standard | |
| Installation and weight | Mounting hole spacing | Distance between upper connection holes: 180mm; distance between lower connection holes: 85mm | Perfectly matched with the original suspension installation point |
| Installation torque requirements | 25-30N·m | Set according to SAE J2538 standard to avoid damage caused by excessive tightness | |
| Net weight | 1.8-2.2kg (due to slight differences in vehicle model adaptation) | Meets the original factory weight standard and does not affect suspension balance |
Here are specific application scenarios of Right Front Shock Absorber:
In response to the frequent start stop and dense speed bumps on urban roads, this Right Front Shock Absorber can reduce the transmission rate of road bumps and vibrations by 25% (in compliance with ISO 18830 testing standards) through a dual tube hydraulic damping structure, alleviating driving fatigue caused by fine vibrations during daily commuting and adapting to mainstream commuting vehicles.
Vehicle stability is crucial during high-speed driving, and the product can reduce vehicle body roll by 18% (third-party measured data). When changing lanes at a speed of 120km/h, the suspension response speed is increased by 30%. Combined with high-pressure nitrogen tank design, it avoids damping attenuation and is suitable for pickup trucks/sedans that often run on highways.
Faced with gravel and bumpy roads, the piston rod 45 # chrome alloy material (surface hardness HRC 58-62) has strong impact resistance and has undergone ASTM B117 salt spray testing for 480 hours without corrosion. It can effectively resist sediment wear and extend its service life in complex road conditions, and is 20% more durable than ordinary shock absorbers.
In low-temperature environments (-40 ℃~120 ℃ temperature range), the sealing components still maintain stable performance, reducing the nodding amplitude by 12% during braking and shortening the braking distance on rainy and snowy roads by about 5%. It is suitable for vehicles in northern regions and solves the safety hazards caused by the "stiffening" of shock absorbers at low temperatures.
When the vehicle is carrying luggage or cargo, the product can maintain stable damping force with a working pressure of 2.5-3.0MPa, avoiding excessive compression of the suspension. In mild off-road situations (such as dirt road climbing), it can cushion the damage of road impact to the chassis and is suitable for multi-purpose household vehicles.
For vehicles that have been in use for more than 3 years and have abnormal noise/oil leakage in the shock absorbers, the product OE code is matched 1:1 with the original factory, with an installation matching degree of 99.2%. After replacement, the original driving texture can be restored, solving the problems of bumpy and blurry steering in old cars.
It is recommended to have personnel with automotive repair qualifications install: first align the suspension installation points according to OE standards, and tighten them with a torque wrench at 25-30N · m (in accordance with SAE J2538 standard) to avoid over tightening and damaging components. Check the seals every 5000 miles daily to ensure no oil leakage; Avoiding long-term overloading during driving and preventing exceeding a working pressure of 3.0MPa can extend the service life of shock absorbers to 80000 to 100000 kilometers.
Q1: Are you manufacturing company?
A: Yes. We are factory, located in Guangzhou. Our factory has certificate of lATF 16949.
Q2: What are your main products?
A: We have steering rack ,steering pump ,wheel hub and bearing ,drive shaft ,alternator,control arm and so on.
Q3: What is the lead time?
A: lt takes 3-7 days when stock is available, and 15-40 days when out of stock.
Q4: What is the warranty?
A: Our guarantee period is 60,000 kilometers or 1 year.
Q5: Do you have samples?
A: Yes, we have samples available. For bulk orders, please inquiry us for more details.
