Product Introduction
2906400-K00 Premium High-strength Reliable Stabilizer Link for Great Wall Motor
Our premium Stabilizer Link (Part No.: 2906400-K00) is built for reliable chassis performance, backed by 15+ years of auto parts engineering experience. It core function is to reduce body roll during turns, enhance driving stability, and minimize vibration transfer for a smoother ride.
Crafted from high-strength steel with anti-corrosion plating, it passes 5,000+ durability cycles and meets ISO 9001 quality standards. Each unit undergoes 3-step strict inspection, ensuring 80,000+ km typical service life and perfect compatibility with target suspensions. A trusted choice for maintaining optimal suspension function.
Product Advantage
1. High-Strength Material & Long-Lasting Durability
Crafted from S50C high-carbon steel (30% higher tensile strength than ordinary steel) and coated with electrophoretic anti-corrosion layers, this stabilizer link resists rust and wear in harsh environments (e.g., humidity, road salt). It passes 5,000+ mechanical durability test cycles and guarantees an 80,000+ km service life—25% longer than industry average. This ensures the high-durability stabilizer link maintains stable performance for years.
2. Precision Manufacturing for Perfect Compatibility
Each 2906400-K00 Stabilizer Link is processed via CNC machining, with dimensional tolerance controlled within ±0.05mm. Our R&D team conducts 1:1 suspension matching tests with original specifications, ensuring seamless fit with target chassis systems. We’ve supplied 50,000+ units to global aftermarket clients since 2018, with a 99.2% compatibility rate—eliminating installation issues for customers.
3. Authoritative Certifications & Strict Quality Control
This stabilizer link fully complies with ISO 9001 and IATF 16949 automotive quality standards, and passes SGS third-party testing for material composition and mechanical properties. Every unit undergoes a 3-step inspection (raw material check → semi-finished product testing → final assembly verification) before shipment. This rigorous process makes the ISO 9001 certified stabilizer link a trusted choice for repair shops and distributors.
4. Enhanced Vibration Reduction & Driving Stability
Equipped with a precision-sealed ball joint (filled with high-temperature resistant grease), the 2906400-K00 Stabilizer Link reduces vibration transfer by 30% compared to standard links. It effectively suppresses body roll during turns, improving driving stability and comfort. Lab tests show it maintains stable torque output (18-22 N·m) even at -40°C to 120°C, adapting to extreme weather conditions.
5. Customer-Centric After-Sales & Installation Support
We provide a 12-month warranty for the 2906400-K00 Stabilizer Link—covering manufacturing defects. Each package includes a detailed installation guide (with torque specifications) and pre-applied anti-loose thread locker, reducing installation time by 15%. Our technical team offers 24/7 online support, solving customer questions about the 2906400-K00 Stabilizer Link within 4 hours on average.
Technical Parameters
| Parameter Category | Parameter Name | Specific Value | Remarks/Certifications |
| Basic Information | Part Number | 2906400-K00 | Unique identification for aftermarket matching |
| Product Type | Front/Rear Stabilizer Link | Compatible with standard suspension anti-roll bar systems |
| Application System | Automotive Chassis Suspension System | Designed for anti-roll bar torque transmission |
| Material Specifications | Main Body Material | S50C High-Carbon Steel | Tensile strength ≥ 650 MPa; Passes SGS material composition testing |
| Ball Joint Material | GCr15 Bearing Steel | Hardness: HRC 58-62; Wear resistance 20% higher than ordinary steel |
| Coating Material | Electrophoretic Plating (Black) | Thickness: 8-12 μm; Resists neutral salt spray for ≥ 480 hours (ASTM B117 standard) |
| Sealing Gasket Material | Nitrile Rubber (NBR) | Operating temperature range: -40°C to 120°C; Oil and aging resistant |
| Dimensional Parameters | Total Length | 185 ± 0.5 mm | Measured from end-to-end of the link |
| Thread Specification | M12 × 1.25 mm (Right/Left Hand) | Matches standard suspension mounting bolts; anti-loose design |
| Ball Joint Diameter | 22 ± 0.05 mm | Machined via CNC; dimensional tolerance controlled within ±0.05 mm |
| Mounting Hole Diameter | 10 ± 0.1 mm | Fits standard suspension bushing pins |
| Performance Parameters | Maximum Load Capacity | 12 kN (Static) | Passes 10,000-cycle dynamic load testing without deformation |
| Operating Temperature Range | -40°C to 120°C | Maintains stable performance in extreme cold/hot environments |
| Service Life (Tested) | ≥ 80,000 km or 5,000+ Durability Cycles | Simulated road testing (ISO 18798 standard); 25% longer than industry average
|
| Vibration Attenuation Rate | ≥ 30% | Reduces vibration transfer from chassis to cabin; tested via frequency response analysis |
| Torque Range (Installation) | 18-22 N·m | Recommended torque for safe mounting; prevents over-tightening damage |
| Certification & Standards | Quality Certifications | ISO 9001, IATF 16949 | Complies with global automotive quality management systems |
| Testing Standards | ASTM B117 (Salt Spray), ISO 18798 (Durability) | All performance data verified by third-party labs (SGS, TÜV) |
| Packaging & After-sales | Package Type | Corrugated Box + EPE Foam Insert | Prevents transportation damage; minimum order quantity (MOQ): 10 units |
| Warranty Period | 12 Months | Covers manufacturing defects; excludes damage from improper installation |
Product Uses
Here are specific application scenarios of Stabilizer Link:
1. Daily Urban Commuting
Ideal for vehicles used in city traffic with frequent starts, stops, and turns. It reduces body roll by 35% (tested per ISO 18798) and cuts vibration transfer by ≥30%, smoothing out jolts from potholes or speed bumps. Its 80,000+ km service life aligns with the average annual mileage of urban vehicles, minimizing replacement frequency.
2. Complex Off-Road & Rural Roads
Suitable for vehicles navigating gravel, muddy, or uneven rural roads. Made of S50C high-carbon steel (tensile strength ≥650 MPa) and electrophoretic coating (480-hour salt spray resistance, ASTM B117), it resists impact and rust. It maintains stable performance even after 5,000+ durability cycles, handling harsh off-road conditions.
3. Commercial & High-Frequency Use Vehicles
Perfect for commercial vehicles (e.g., delivery vans) with high daily mileage. Certified by IATF 16949, it withstands continuous load pressure (max static load 12 kN) without deformation. We’ve supplied 50,000+ units to commercial fleets, with a 98.7% positive feedback rate for its long-term reliability.
4. Professional Repair & Aftermarket Replacement
A top choice for auto repair shops and distributors. With a 99.2% compatibility rate (verified via 1:1 suspension matching tests) and ISO 9001 certification, it avoids installation errors. The included torque guide (18-22 N·m) and anti-loose thread locker reduce repair time by 15%, boosting shop efficiency.
5. Extreme Climate Regions
Adaptable to areas with extreme temperatures (from -40°C to 120°C). Its NBR sealing gasket resists aging and oil, while the ball joint (GCr15 steel, HRC 58-62) stays flexible in frigid or scorching weather. It’s been tested in 12+ countries with extreme climates, maintaining consistent stability.
Product Operate Guide
Securely lift the vehicle and stabilize it.
Remove the old link with a socket wrench; clean the suspension mounting area.
Align the 2906400-K00 link with mounting points, fasten bolts using a torque wrench set to 18-22 N·m (critical for load resistance).
Test for loose movement—ensure no gaps; lower the vehicle and check stability during a short drive.
