Product Introduction
T11-1602020 Clutch Master Cylinder for Chery Tiggo
Our B1608100 Clutch Master Cylinder is a premium hydraulic core component tailored for Lifan, designed to ensure stable clutch system operation. It converts pedal force into hydraulic pressure accurately, enabling smooth gear shifts and preventing issues like clutch sticking or delayed response.
Manufactured in line with ISO 9001 quality standards, it adopts high-pressure resistant cast iron casing and EPDM seals. The product supports a working pressure of 8-12 MPa and boasts a service life of over 50,000 kilometers. Backed by 12+ years of auto parts engineering experience, it ensures precise fitment and comes with a 12-month warranty, meeting global aftermarket demands.
Product Advantage
1. ISO 9001-Certified Quality with Premium Materials
As an ISO 9001 certified clutch part, this B1608100 Clutch Master Cylinder adopts high-pressure resistant cast iron casing (tensile strength ≥ 250 MPa) and industrial-grade EPDM seals. These materials undergo 500+ hours of anti-corrosion testing, effectively resisting oil leakage and wear caused by extreme temperatures (-40℃ to 120℃). The strict certification and material selection ensure consistent performance in harsh operating conditions.
2. Long-Life Design Backed by Real-World Data
This long-life clutch master cylinder boasts a service life of 50,000+ kilometers, verified by third-party durability tests. Unlike ordinary alternatives that may fail after 20,000 kilometers, its internal piston uses a chrome-plated finish (thickness 0.02mm) to reduce friction by 30%. This design not only extends replacement cycles but also lowers long-term maintenance costs for end-users.
3. Precise Fitment for Hassle-Free Installation
Leveraging advanced 3D scanning and laser measurement technology (precision ±0.01mm), the B1608100 Clutch Master Cylinder achieves 100% fitment accuracy with target vehicle systems. Our engineering team has analyzed 2,000+ aftermarket installation cases to optimize mounting points, reducing installation time by 40% compared to generic clutch master cylinders. No additional modifications are needed, minimizing installation errors.
4. Stable Hydraulic Performance for Smooth Operation
The core hydraulic chamber of this premium auto hydraulic component features a optimized flow channel design, ensuring pressure conversion efficiency of 95%+. It maintains stable hydraulic pressure (8-12 MPa) even during frequent clutch engagements, preventing issues like delayed gear shifts or clutch sticking. Real-road tests show it reduces clutch pedal vibration by 25%, enhancing driving comfort.
5. Global After-Sales Support & Warranty
Every B1608100 Clutch Master Cylinder comes with a 12-month global warranty, covering manufacturing defects and performance failures. We have 5 regional warehouses worldwide, enabling 2-5 day delivery to major markets (North America, Europe, Southeast Asia). Our technical support team (available 24/7 via email/phone) provides professional troubleshooting guidance, resolving 90% of customer issues within 24 hours.
Technical Parameters
| Category | Specification | Details/Standards |
| Basic Information | Product Model | B1608100 |
| Applicable Brand | Lifan |
| Product Type | Hydraulic Clutch Master Cylinder |
| Production Standard | ISO 9001:2015, IATF 16949 (automotive quality management system)
|
Material Parameters
| Cylinder Body Material | HT250 Gray Cast Iron; Tensile Strength ≥ 250 MPa; Hardness 180-220 HB |
| Piston Material | 45# Carbon Steel with Chrome Plating; Plating Thickness 0.02-0.03 mm; Surface Roughness Ra ≤ 0.8 μm |
| Seal Material | EPDM Rubber; Temperature Resistance: -40℃ to 120℃; Oil Resistance: Compatible with DOT 3/DOT 4 fluid |
| Spring Material | 65Mn Steel; Elasticity Loss ≤ 5% after 10,000 cycles of compression |
| Performance Parameters | Working Pressure Range | 8-12 MPa (steady state); Peak Pressure Resistance ≤ 15 MPa (short-term) |
| Pressure Conversion Efficiency | ≥ 95% (tested under standard temperature 25℃) |
| Service Life | ≥ 50,000 km (under normal driving conditions) |
| Leakage Rate | ≤ 0.1 mL/min (tested at 12 MPa static pressure for 30 minutes) |
| Response Time | ≤ 0.3 seconds (from pedal depression to pressure build-up) |
| Dimension Specifications | Cylinder Bore Diameter | 22 mm (Tolerance: ±0.01 mm) |
| Total Length (from Top to Bottom) | 185 ± 1 mm |
| Oil Inlet Port Specification | M12×1.25 (Metric Thread); Sealing Type: O-ring (Φ16×2.4 mm) |
| Oil Outlet Port Specification | M10×1.0 (Metric Thread); Sealing Type: Copper Washer (Φ12×Φ10×1 mm) |
| Mounting Hole Spacing | 60 ± 0.5 mm (center-to-center distance of two mounting holes) |
| Certification & Compliance | Environmental Compliance | RoHS 2.0 (restriction of hazardous substances); REACH (190+ SVHCs not detected) |
| Applicable Fluid | DOT 3 / DOT 4 Brake & Clutch Hydraulic Fluid |
| Storage Environment | Temperature 0℃-40℃; Relative Humidity ≤ 75%; No corrosive gas |
Product Uses
Here are specific application scenarios of Clutch Master Cylinder:
1. Aftermarket Repair & Replacement
It is the first choice for repairing faulty clutch master cylinders—such as those with oil leakage, weak pedal feel, or delayed gear shifts. Over 85% of our cooperative auto repair shops prioritize this model for replacements, as its 100% fitment accuracy cuts installation time by 30% compared to generic parts, ensuring quick vehicle return to service.
2. Commercial Fleet Maintenance
For commercial fleets (e.g., delivery vehicles, logistics trucks) that require high durability, this component extends maintenance intervals to 50,000+ km—20% longer than average OEM alternatives. Fleet customers report a 15% reduction in annual clutch-related downtime, directly lowering operational costs.
3. Extreme Climate Operations
It performs stably in regions with extreme temperatures, from -40℃ (Northern Europe, Siberia) to 120℃ (Middle East deserts). Third-party tests show a 98% performance stability rate under such conditions, while its EPDM seals resist aging 1.5x longer than standard seals, avoiding climate-induced failures.
4. Performance Tuning & Modification
For enthusiasts modifying vehicles for better handling, its 95%+ pressure conversion efficiency ensures precise clutch control. It supports frequent high-load engagements (e.g., during track days) without pressure loss, and users note a 0.2-second faster gear shift response compared to stock clutch master cylinders.
5. Global Aftermarket Distribution
Compliant with auto parts standards across Europe, North America, and Southeast Asia, it fits seamlessly into global distribution networks. Our 5 regional warehouses enable 2-5 day delivery to key markets, with 90% of wholesale orders dispatched within 48 hours—ideal for distributors needing fast stock replenishment.
Product Operate Guide
Follow professional procedures aligned with ISO 9001 guidelines to ensure optimal performance and avoid 80% of installation-related issues.
First, inspect the part visually—check for casing cracks or seal damage (0 tolerance for defects). Install by aligning mounting points (matches 100% fitment specs) and torque bolts to standard values. Fill with DOT 3/DOT 4 fluid (reduces 90% fluid-compatibility failures) and bleed air until the clutch pedal feels steady.
For daily use, check fluid levels monthly (low levels cause 60% of premature wear) and avoid extreme impacts. Service every 50,000 km as recommended to maintain efficiency.
