1014002432 Rear Suspension Dust Boot (Plastic) for Geely MK

Product Introduction

1014002432 Rear Suspension Dust Boot (Plastic) for Geely MK

The Rear Suspension Dust Boot (Plastic) is a critical protective component for vehicle rear suspension systems, mainly covering suspension ball joints or bushings. Made of high-density polyethylene (HDPE) with anti-aging additives, it boasts good impact resistance and weather resistance, enduring -30℃~80℃ temperature changes without cracking.

Its core function is to block dust, sand, rainwater and road impurities from entering the suspension moving parts, avoiding premature wear of components. It fits most mainstream models, supports direct OEM replacement, is easy to install, and effectively maintains stable rear suspension operation to ensure driving comfort.

Product Advantage

1. High density HDPE material, weather resistance and anti-aging at -30 ℃ to 80 ℃: food grade high density polyethylene (HDPE)+2% anti-aging master batch injection molding, material tensile strength ≥ 28MPa, elongation at break ≥ 400%. After 1200 hours of high and low temperature cycling testing (-30 ℃~80 ℃), there were no cracks or deformations, far exceeding the weather resistance standard of ordinary plastic dust covers for 800 hours, ensuring long-term stable operation of the high-density polyethylene suspension dust boot.

2. IP67 dustproof and waterproof rating, with a 50% extension of component life: The boot body adopts an integrated sealing structure, and the interface is equipped with a EPDM rubber sealing ring, with a protection level of IP67 (completely dustproof, can be soaked in water for a short time). Tested to be able to block 99% of road dust, rain, and oil from entering the suspension ball head/liner, reducing the wear rate of core components by 50% and extending the service life of the suspension system to more than 6 years.

3.1:1 OEM precise adaptation, 10 minute quick installation: strictly follow the original factory drawings for mold opening, with a shoe size error of ± 0.1mm and installation hole alignment accuracy of ≤ 0.05mm, compatible with 20+mainstream brand models. No need to modify the original car structure, it can be fixed with conventional clamping tools. Ordinary maintenance personnel can complete the installation within 10 minutes, solving the OEM compatible rear suspension dust boot adaptation problem.

4. High impact and friction resistance, suitable for complex road conditions: The material has been specially modified, with a low-temperature (-30 ℃) impact strength of 15kJ/m ² (industry average 10kJ/m ²), a surface friction coefficient of only 0.18, and can withstand high-frequency expansion and contraction friction of the suspension system (no damage after 5000 cycles of testing). Adapt to complex road conditions such as bumpy mountain roads and muddy roads, avoiding damage to dust covers due to impact or friction.

5. Full process quality inspection with a defect rate of ≤ 0.3%: Six quality inspection processes are set up from raw material entry to finished product delivery (size inspection, weather resistance testing, sealing testing, impact testing, etc.), and 8% of products are randomly selected from each batch for real vehicle suspension simulation testing. Relying on the ISO9001 quality management system, the product defect rate is steadily controlled below 0.3%, far below the industry average of 1.2%, ensuring product quality.

6.12 months warranty+free technical support, worry free after-sales service: provides an 12 month extended warranty period, during which material aging, cracking and other quality problems can be replaced for free; Support 7-day no reason return and exchange policy, and bear the round-trip shipping cost. Our professional team is online 24 hours a day and can provide vehicle adaptation inquiries and installation video guidance, dispelling customers' concerns about purchasing wear resistant rear suspension dust boots.

Technical Parameters

1. Material parameters: The main body is made of Q235 cold-rolled galvanized steel plate with a thickness of 1.5mm; the surface has undergone cathodic electrophoretic rust prevention treatment with an electrophoretic film thickness of 8-12 μ m; The material has a tensile strength of ≥ 550MPa, a yield strength of ≥ 345MPa, and a low temperature (-40 ℃) impact toughness of ≥ 18J/cm ². It can pass the 500 hour neutral salt spray test (GB/T 10125-2021 standard) without corrosion or coating peeling.

2. Size specifications: The main dimensions of the product (length x width x height) are 120mm x 85mm x 35mm (with an error of ± 0.1mm); There are 2 installation holes with a diameter of 8mm (tolerance H7) and a center to center distance of 60mm (error ± 0.02mm); The depth of the buckle groove is 5mm, the width is 10mm, and it is suitable for parking brake cables with a diameter of 6-8mm.

3. Scope of adaptation: Compatible with over 30 mainstream vehicle models, including the right rear parking brake system; The compatible parking brake type is mechanical parking brake.

4. Performance parameters: Operating temperature range -40 ℃~80 ℃, with no structural deformation or functional degradation within this temperature range; Maximum tensile strength of 1200N (static load), continuous loading for 30 minutes without fracture or permanent deformation; Braking cable positioning accuracy ≤ 0.5mm, ensuring stable braking stroke; The overall weight of the product is 280g ± 5g, which meets the lightweight design requirements of the original vehicle.

5. Process standard: Using a 160 ton punch press for integrated stamping, with a forming accuracy of ± 0.1mm; the installation hole adopts a secondary tapping process, with a thread accuracy of 6H, suitable for M8 × 1.25 bolts; The edges are rounded with a radius of R1.5mm to avoid scratching the cable or hands during installation; The finished product needs to go through 8 quality inspection processes (size testing, tensile testing, temperature resistance testing, etc.) before leaving the factory.

6. Certification compliance: The product complies with ISO9001:2015 quality management system certification; The material complies with RoHS 2.0 environmental standards (restricting harmful substances such as lead and cadmium); The braking performance related indicators comply with SAE J2492 (General Standard for Automotive Brake System Components); The packaging complies with ISTA 3A transportation packaging standards, ensuring no damage during transportation.

Product Uses

Here are specific application scenarios of Rear Suspension Dust Boot:

1. Scenario of replacing the aging/damaged dust cover of the original vehicle: When the vehicle experiences abnormal noise from the rear suspension and increased bumps, and inspection reveals that the original plastic dust cover has cracked and hardened due to aging, causing sand and dust to invade the ball head/liner, the Rear Suspension Dust Boot (Plastic) can be directly replaced to quickly restore protection and avoid further component wear.

2. Suspension maintenance scenario in repair shops: When dealing with suspension faults of compatible vehicle models, the repair shop replaces the ball joint or bushing and matches it with the HDPE rear suspension dust boot. There is no need to adjust the installation position, and it can be installed in 10 minutes, which can synchronously improve the integrity of maintenance and reduce the subsequent repair rate.

3. Adverse road condition protection scenario: When vehicles often drive on muddy roads, gravel roads, or dusty areas, ordinary dust covers are easily scratched by gravel and rainwater infiltration. However, this dust cover has IP67 protection performance, which can block impurities from entering and ensure stable operation of suspension components in complex road conditions.

4. Preventive maintenance scenario for old vehicles: For vehicles over 5 years old, the original dust cover is prone to long-term temperature changes and friction aging. Replacing the aging resistant dust cover in advance can avoid suspension failures caused by sudden damage during subsequent driving, reduce the risk of mid journey breakdowns, and extend suspension life.

5. Suspension component modification adaptation scenario: After modification enthusiasts replace aftermarket suspension ball joints or bushings, if the original car dust cover size does not match, the multi specification adaptation Rear Suspension Dust Boot (Plastic) can accurately fit the new component to ensure protection is not missing.

Product Operate Guide

1. Prepare clamp pliers and a cloth. First, loosen the clamps on both ends of the Rear Suspension Dust Boot (Plastic) of the original car, remove the damaged old parts, and use a cloth to wipe off any impurities on the surface of the suspension ball head/bushing;

2. Align the new dust cover with the component and tighten the clamps at both ends with clamp pliers (moderate force to avoid fracturing the plastic);

3. Gently shake the suspension and check that the dust cover is not displaced, fits tightly, and has no loose gaps before installation is complete. The entire process takes about 15 minutes.

FAQ

Q1: Are you manufacturing company?

A: Yes. We are factory, located in Guangzhou. Our factory has certificate of lATF 16949.

Q2: What are your main products?

A: We have steering rack ,steering pump ,wheel hub and bearing ,drive shaft ,alternator,control arm and so on.

Q3: What is the lead time?

A: lt takes 3-7 days when stock is available, and 15-40 days when out of stock.

Q4: What is the warranty?

A: Our guarantee period is 60,000 kilometers or 1 year.

Q5: Do you have samples?

A: Yes, we have samples available. For bulk orders, please inquiry us for more details.
